AMT Datasouth 600 - Manual (Page 23)

User Manual 21
11. Close and latch the print head module. Be sure to press firmly on both sides so that both
latches clink into place. If either latch is not clicked into place it will cause the media to not
feed properly or print light.
Figure 20 – Print head Module Closed
12. Close the Top Media Cover.
13. Press the Feed Button to correctly position the next Top of Label.
Note: The first time media is installed, the Media Sensor must be calibrated. After the first
calibration no further calibration is required unless the media type (length, color,
backing material, etc.) is changed or irregular feeding occurs. Refer to the section
Calibrating Media Sensors for instructions on how to calibrate the media sensor.
