Appendix E: Parts Lists and Mechanical Drawings
ITEM PART NO. DESCRIPTION QTY DETAIL
1 90.R4002.001 COVER MODULE 1 B
2 39.R4002.003 MIDCOVER 1 B
3 39.R4004.004 BOTTOM USB 1 D
4 90.R4001.005 CHASSIS MODULE 1 C
5 90.R4003.007 CHASSIS2 MODULE V7 1 D
6 42.R4004.003 PAPER-GUIDE (R) V3 1 D
7 42.R4003.003 PAPER-GUIDE (L) V3 1 D
8 32.R4004.001 GEAR 33T 3 D
9 35.R4004.003 SHAFT -FIBER 2 C,D
10 34.R4004.001 BUSH 4 4 D
11 42.R4010.001 BUSH-RIBBON 1 D
12 47.R4001.001 FIBER 4 D
13 40.R4005.001 PL ATE -FIBER 1 D
14 34.R4010.002 SPRING-FIBER2 1 D
15 42.R4011.001 BUSH-RIBBON 2 D
16 34.R4007.002 SPRTNG-RIBBON2 1 D
17 34.R4009.002 SPRTNG-FIBER1 1 D
18 33.R4010.001 BRACKET -SPRING 1 D
19 34.R4001.001 BUSH 1 4 D
20 47.A2008.011 RUBBER- USB (BLACK) 1 D
21 32.R4003.001 GEAR 66 T 1 D
22 33.R4009.001 BRACKET-FIBER 1 D
23 33.R4001.001 BRACKET -GEAR1 1 D
24 32.R4005.001 GEAR 46T 1 D
