52 User Manual
Appendix A: General Specifications
Specifications Fastmark 602 and 612 Fastmark 603
Printing method Direct thermal or Thermal Transfer
Printing resolution
203 dpi (8 dots/mm) 300 dpi (12 dots/mm)
Printing speed 2 ~ 6 ips
(51~150 mm/s) 2 ~ 4 ips
(51~ 102 mm/s)
Printing length 0.4” ~ 43”
(10 mm ~ 1092 mm) 0.4” ~ 14”
(10 mm ~ 355.6 mm)
Printing width Max 4” (101.6 mm) Max 4” (101.6 mm)
Memory 2MB DRAM
1MB Flash ROM
CPU type 32 bit RISC microprocessor
Media sensor Reflective (Movable)
Display Three LED indicators
Operation interface Three Buttons
Communication interfaces Centronics parallel
RS-232 serial
Fonts (Emulation Dependent) Int’l character sets standard
5 alpha-numeric fonts from .049”~ .23”H (1.25mm~6.0mm)
All fonts are expandable up to 24x 24
4 direction 0º~270º rotation
Soft fonts are downloadable
2D Barcodes Maxicode, PDF-417, Data Matrix
Graphic PCX bit map, GDI graphics
Software (Emulation) PPLA or PPLB Language
PPLZ (FM612 only)
Windows Driver (Win 98/2000/NT/XP)
Label editing software – Xbar Lite
Media Roll-feed, die-cut, continuous, fan-fold, tags, ticket in thermal paper or
plain paper and fabric label
Max width 4.3” (110 mm)
Min width 0.6” (15 mm)
Thickness .0025”~. 01” (.0635mm ~. 254mm)
Max roll capacity 6” (OD 152 mm)
Core size 1” (ID 25mm) (3” ID Core can be used with media core adapter)
Ribbon Wax, Wax/Resin, Resin (inside costing)
Ribbon width – 4” (smaller widths can be used with Ribbon Core adapter)
Ribbon roll – max 2.67” (OD 68 mm)
Ribbon length – re-sin 300 m , wax 360 m (OD 68 m)
Core size - ID 1” core (25 mm)
Mechanism information Built-in Tear off bar, front-open cover, clear window, fan fold paper slot,
wound-in ribbon, TPH carrier not adjustable.
Weight 9.3 lbs (4.2 kgs)
Power source Auto Sensing Power supply (90 ~ 250 VAC)
Agency listing CE, UL, CUL, FCC class A, CCC
Operation environment 40ºF ~ 100ºF (4ºC~38ºC)
10~90% non condensing
Optional items Cutter, Dispenser kit, Real time clock card
Note: Fonts, Graphics, Character sets and Barcodes will differ between PPLA, PPLB and PPLZ
emulations.
