HP StorageWorks SN6000 Fibre Channel Switch QuickTools Switch Management User Guide 69
Network IP configuration
The IP configuration identifies the switch on the Ethernet network, determines which network discovery
method to use, and enables/disables the IPv4 and IPv6 network addressing.
IPv4 and IPv6 addressing
An IPv4 address is 32 bits and consists of four blocks of decimal numbers, with each block separated by a
period. Each block can have up to three numbers. A single zero character displayed in a block indicates
that the block consists of all zeroes. An example of an IPv4 address is 255.255.255.0. All four blocks
contain numbers. Table 12 describes the IPv4 and IPv6 configuration parameters.
An IPv6 address provides a much wider range of IP addresses than an IPv4 address. An IPv6 address is
128 bits, and consists of eight blocks of hexadecimal numbers, with each block separated by a colon. The
maximum number of numerals in each block is four. One or more blocks with all zeroes are represented by
two colon characters. The total number of blocks always adds up to eight. To determine how many
contiguous blocks contain only zeroes, subtract the number of populated blocks from eight. For example,
the IPv6 address 2eee::49:24:7a:54:3434 is equivalent to 2eee:0000:0000:49:24:7a:54:3434. The
number of blocks containing zeroes in this example is two (8-6=2).
NOTE: Switches without IPv6 addressing enabled can not communicate over Ethernet with hosts or
switches using the IPv6 addressing.
Table 12 describes the network IP configuration parameters.
Table 12 Network Properties dialog box—IP fields
Field Description
IPv4 Network Enable this option to permit the IPv4 addressing format to
be used anytime you are required to enter an IP address.
CAUTION: Disabling this option will prevent you from
using an IPv4 IP address for system services.
IPv6 Network Enable this option to permit the IPv6 addressing format to
be used anytime you are required to enter an IP address.
CAUTION: Disabling this option will prevent you from
using an IPv6 IP address for system services.
