Characters
Values
Description
Parameter
Column
16 hexadecimal
digits
0000000000000000
to
FFFFFFFFFFFFFFFF
WWN of the alternate path.
WWN
C
Third Layer: Information about LDEVs to be created in an external volume.
N/A
N/A
Identifier
+
A
+
B
2 hexadecimal
digits or less
00 to 01
LDKC number
LDKC
C
2 hexadecimal
digits or less
00 to FE
CU number
CU
D
2 hexadecimal
digits or less
00 to FF
LDEV number. Specify a number that is not currently
assigned. LDEV numbers may be assigned in another
LDEV
E
emulation group (grouped by 32 LDEV numbers), in which
case they cannot be used.
For more information about emulation groups, see the HP
P9000 Provisioning for Open Systems User Guide or the
HP P9000 Provisioning for Mainframe Systems User
Guide.
Check to see if a number is assigned. To do this, open
RWC and check the LDEV tab on the Basic Information
Display dialog box (File > Go > Basic Information).
10 decimal digits
or less
1 to
8589934592
Capacity of the LDEV in blocks.
For more information on how to calculate LDEV size in
blocks and emulation considerations, see
Capacity
F
4 hexadecimal
digits or less
0004 to FFFE
SSID assigned to the range of the LDEV numbers. Use the
SSID shown in the output file from the
SSID
G
ExternalStorage_Get_def.spd
spreadsheet for the
range. If you create an LDEV that does not have any SSID,
specify an SSID that is not written in the output file.
For more information on SSIDs, see the HP P9000
Provisioning for Open Systems User Guide or the HP
P9000 Provisioning for Mainframe Systems User Guide.
Example of mapping external volumes with multiple LDEVs
#!Version 06_01_00,CLI_ExternalStorage,VolumeOperationFibre,;
[SerialNumber]
65536,;
[AddVolumeSetting]
1,1A,60060E8004F81370,0001,E16384-4095,Normal,00,OPEN-V,Enable,Disable,;
+,1B,60060E8004F81371,;
+,+,00,00,00,96000,0004,;
+,+,00,01,00,96000,0005,;
+,+,00,02,00,96000,0006,;
