61
The following sections describe the configuration of each tab and how to use the tabs to operate the
TC390 functions (see ”
Performing TrueCopy Pair Operations
” on page 109 for TC390 volume pair
configuration).
TrueCopy Main Window (Pair Operations Window)
The first window that is displayed after clicking the TrueCopy button is the TrueCopy main window, also
known as the Pair Operations window. To display this window at any time, click the Pair Operations tab
from any of the other TrueCopy windows.
The TrueCopy main window displays information for the selected CU image of the connected disk array.
From this window, you can configure the volume pairs. This section describes the components of the
TrueCopy main window. For the information about the TC390 volume pair configuration, see ”
RCU Operations RCU Status
Displays the RCU status and TC390 port numbers that are
already set.
RCU Operation >
Add RCU
Registers the RCU at the remote disk array. RCU controls the
R-VOL of the TC390 volume pair.
RCU Operation >
Delete RCU
Deletes the RCU that is already registered.
RCU Operation >
Change RCU Option
Modifies the options for RCUs that are already registered.
Edit SSID(s) & Path(s) >
Add Path
Adds the paths to RCUs.
Edit SSID(s) & Path(s) >
Delete Path
Deletes the paths to RCUs.
Edit SSID(s) & Path(s) >
Add SSID
Adds the SSIDs of RCUs that are connected to MCU.
Edit SSID(s) & Path(s) >
Delete SSID
Deletes the SSIDs of RCUs that are already connected to MCU.
Port
Sets or changes the port type at the MCU (Target, RCU Target
or Initiator).
Asynchronous
Operations
Async Option
Sets and modifies the asynchronous copy options.
CT Group Operation >
CT Group Status
Displays the information of the consistency groups that are
already registered.
CT Group Operation >
Add CT Group
Assigns the CUs to the consistency groups.
CT Group Operation >
CT Group Option
Modifies the settings for the consistency groups that are already
assigned.
CT Group Operation >
Delete CT Group
Deletes the consistency groups that are already assigned.
Usage Monitor
-
Obtains the I/O statistics using the Remote Copy Monitoring
function.
Script
Operations
-
Uses the script function.
History
Operations
-
Displays the operation history of TC390 volume pairs.
Other
Operations
Clear SIM
Clears all the remote copy SIMs.
Table 16
TC390 functions (continued)
Tab
Menu Command
Description
