150 TrueCopy for the XP128/XP1024/XP10000/XP12000
CAUTION:
Before issuing the CESTPATH command, verify that the relevant paths are offline from the
host(s) (for example, configure the Chipid offline, deactivate the LPAR, or block the port in the ESCD). If any
active paths still exist, the add path operation will fail because the port mode cannot be changed.
NOTE:
For Fibre Channel interface, do not use the CESTPATH and CDELPATH commands at the same
time as the SCSI path definition function of LUN Management. The Fibre Channel interface ports need to
be configured as initiator ports or RCU target ports before the CESTPATH and CDELPATH commands are
issued.
The following table describes the CESTPATH LINK parameter for serial and Fibre Channel interface.
The following table gives the XP128/XP1024/XP10000/XP12000 system adapter ID (SAID) values for the
CESTPATH LINK parameter.
•
The last two digits of the link parameter must specify the logical CU number (00-1F for an
XP128/XP1024/XP10000/XP12000, 00-0F for an XP256).
•
For 3990 controller emulation, the first two digits can be 00, 01, or 02. This option controls freeze as
follows:
00 = use mode 104
01 = freeze enabled
02 = freeze disabled
Table 32
CESTPATH LINK parameter for serial and Fibre Channel
LINK Parameter
Serial (ESCON) Interface
Fibre Channel Interface
aa
First two digits of SAID,
see
.
FREEZE option
0x00:keep the status
0x01:Enabled
0x02:Disabled
When there are several paths, the same
values must be specified for all the
paths.
Bit 0-3: RCU controller ID
x2-xF: Number stands for RCU
controller ID.
(x’4’ is specified.)
Bit 4-7: FREEZE option
x0:keep the status
x1:Enabled
x2:Disabled
When there are several paths, the same
values must be specified for all the
paths.
bb
Second two digits of SAID,
see
.
MCU port number (0x00-0x1f)
MCU port number (0x00-0x1ff)
cc
Link Adr (0x00-0xff)
RCU port number (0x00-0x1ff)
dd
CU number (0x00-0x1f)
CU number (0x00-0x3f)
