TrueCopy for z/OS user guide 171
NOTE: For more information on HXRC device blocking and load balancing control, refer to ” HXRC
Device Blocking and Load Balancing ” on page 201.
Pinned Track Recovery for TrueCopy Volumes
If a pinned track occurs on a TC390 M-VOL or R-VOL, the MCU will suspend the pair (SIM reference code
= D41x, D42x, DB1x, DB2x). Use the following procedure to ensure full data integrity of the volume pair
while recovering the pinned track:
1. Connect to the MCU of the TCz pair that contains the volume with the pinned track, and select the
correct CU image.
2. Delete the TCz pair that contains the volume with the pinned track.
NOTE: If you delete the TCz pair containing the volume with the pinned track, delete only the pair
containing the volume with the pinned track. To delete only the TCz Asynchronous volume pair
containing the volume with the pinned track, select Volume for Asynchronous Parameters and
Delete Range.
3. If the volume is offline (for example, R-VOL has pinned track)), vary the volume online.
4. Perform your usual procedure for recovering data from a pinned track. Refer to the pinned track
recovery procedures for your operating system. Contact your HP account support representative to
inform them of the pinned track.
5. If the volume was previously offline (for example, R-VOL), make sure to vary the volume offline again.
6. Restart the volume pair using the Add Pair window, making sure to use the Entire initial copy option.
NOTE: Be sure to specify the volume pair for which the pinned track recovery operation was performed.
SIM Reporting
The XP128/XP1024/XP10000/XP12000 reports a service information message (SIM) to the host when it
is necessary to notify the user of a possible service requirement for the disk array. The SIMs are classified
according to severity for reporting and logging purposes: service, moderate, serious, or acute. The SVP
reports all SIMs related to TC390 operations and all SIMs are stored on the SVP for use by HP personnel.
The SIMs reported to the zSeries and S/390 host are logged in the SYS1.LOGREC dataset of the host
operating system. Each time a SIM is generated, the amber Message LED on the
XP128/XP1024/XP10000/XP12000 control window (under the Ready and Alarm LEDs) turns on as an
Primary disk array
interface
Parallel or ESCON ESCON only ESCON only
Secondary disk array
interface
Parallel or ESCON Parallel or ESCON Parallel or ESCON
Channel extender
support
Yes Contact your HP account
support representative for the
latest information.
Contact your HP account
support representative for the
latest information.
Maximum sidefile size 50% 50% available cache 50% available cache
Sidefile puncture % 60% 60%. Retries issued at 40%
utilization, host interface
blocked at 50% utilization.
60%. Retries issued at 40%
utilization, host interface
blocked at 50% utilization.
Table 41 GDPS-TC390-HXRC matrix (continued)
zSeries and S/390
Feature
IBM 3990-6E XP128/XP1024/XP10000/
XP12000
XP48/XP512
