Figure 6
1 Handle
2 Pick assembly
This provides easy access to the rollers (3) and separator pad (4), as shown in
Figure 7.
Figure 7
3 Rollers
4 Separator pad
2 Lightly dampen a clean lint-free cloth with distilled water, then squeeze any
excess liquid from the cloth.
3 Use the damp cloth to wipe any residue off the rollers or separator pad.
4 If the residue does not come off using distilled water, try using isopropyl
(rubbing) alcohol.
5 Use the blue-green handle to lower the pick assembly.
To reattach the face plate to the front of the automatic document feeder
1 As shown in Figure 8, hook the face plate onto the left side of the HP all-in-one
so that the plastic catch (2) on the far left inside of the face plate catches on
the notch (1) on the front of the automatic document feeder.
Chapter 16
196 HP Officejet 7300/7400 series all-in-one
Troubleshooting
information
