13. Press the key, and then the OK key to display the media advance calibration value.
14. Enter the media advance adjustment value, and press the OK key.
Set a numeric value with the and keys.
NOTE Select a mean value if the media advance value is different in every color. If you
have an image that uses one particular color, then set the value based on that color.
Set a mean value if the media advance value differs between the left and right sides of the
media.
Different values between the left and right sides of the media may be caused by skew.
15. Press the OK key to confirm.
Printhead position adjustment
Use the printhead print position test patterns to calibrate the following printhead positions:
● Printhead to printhead position — adjusts the printhead position for the scan axis using the black
printhead as a reference.
● Bidirectional printing position.
To print the printhead to printhead position pattern:
1. In the TEST PRINTS menu scroll to the PH TO PH option and press the OK key.
2. Press the OK key to start printing.
ENWW How do I calibrate my printer 121
