Storage tab—Displays the unallocated space, used space, free space on the volume, and also
details on your volume or logical disk properties, depending on the application open:

Table 26 Storage tab: HP Storage System logical disk properties

Value

Property

Name the system uses to identify the logical disk.

System Name

Globally unique identifier(s) of the hard drive(s) used by the logical disk for
storage.

Physical Disks

Indicates if the logical disk is configured with exclusive storage. See

“Advanced

Storage Properties items” (page 19)

for more information.

Exclusive Storage

The RAID level to which the logical disk is configured. See

“Customizing RAID

levels” (page 20)

for more information.

RAID Level

The RAID stripe size to which the logical disk is configured. See

“Advanced

Storage Properties items” (page 19)

for more information.

RAID Stripe Size

Speeds up reads when enabled. This setting is determined by the storage array,
not ASM.

Read Cache

Speeds up writes when enabled. This setting is determined by the storage array,
not ASM.

Write Cache

The number of hot spares with which the logical disk is configured. See

“Advanced Storage Properties items” (page 19)

for more information.

Number of Hot Spares

Space on the logical disk used to store data that is not managed by ASM.

Unmanaged Data

Unused storage space on the logical disk that is not allocated.

Free Space

Table 27 Storage tab: HP Storage System volume properties

Value

Property

Name of your HP Storage System.

Storage System Host Name

Name of the volume on your HP Storage System.

Storage System Volume - Name

Status of the volume on your HP Storage System.

Storage System Volume - Status

Indicates if volume is configured with exclusive storage. See

“Advanced Storage

Properties items” (page 19)

for more information.

Storage System Volume - Exclusive
Storage

The RAID level to which the volume is configured. See

“Customizing RAID levels”

(page 20)

for more information.

Storage System Volume - RAID Level

The RAID stripe size to which the volume is configured. See

“Advanced Storage

Properties items” (page 19)

for more information.

Storage System Volume - RAID Stripe
Size

Speeds up reads when enabled. This setting is determined by the storage array,
not ASM.

Storage System Volume - Read Cache

Speeds up writes when enabled. This setting is determined by the storage array,
not ASM.

Storage System Volume - Write
Cache

The number of hot spares with which the shared folder's storage is configured.
See

“Advanced Storage Properties items” (page 19)

for more information.

Storage System Volume - Number of
Hot Spares

Path on which the volume on your HP Storage System is mounted.

Storage System Volume - Mount Paths

Application Server View

Application Server View lists your HP Storage System and the application servers with storage
hosted on your HP Storage System. Expand HP Storage System to display the top-level shared

48

Monitoring storage
