8. Ensure there is no space between the roll and the blue stop.
If you are a regular user of different paper types, you can change rolls more quickly if you pre-load rolls
of different paper types on different spindles. Extra spindles are available for purchase.
Load a roll into the printer [4520]
NOTE: This topic applies to the HP Designjet 4520 Printer series only.
To start this procedure you need to have a roll loaded on the spindle. See Load a roll onto the spindle
[4520] on page 31 .
1. At the printer's front panel, select the icon, then Paper load > Load roll 1 or Load roll 2.
TIP: This step is optional. You may skip it and start the loading process without using the front
panel, by pulling out the drawer as shown below.
ENWW Load a roll into the printer [4520] 33
