NOTE: If you use VM Manager to manage a VM Host running Integrity VM Version 3.5 or
earlier, VM Manager does not fully support virtual device special files located in /hpap
(introduced in HP StorageWorks Secure Path software Version 3.0F SP2) as backing devices for
virtual storage. If a virtual storage device using an /hpap device special file already exists on a
virtual machine managed by VM Manager, VM Manager displays it on the VM Host Storage
and VM Properties Storage tabs as an unknown device (using the question mark icon, ). VM
Manager displays the correct device special file name (for example, /hpap/rdsk/hpap1) but
the box representing this device is not connected to the boxes that represent the physical storage
devices associated with that virtual device special file. In general, VM Manager correctly displays
only those device special files located in /dev.
Screen details
Storage tab column layout
Figure 4-14 depicts the column layout for the VM Host Storage tab.
Figure 4-14 Storage tab column layout
The VM Host Storage tab consists of three columns with the following titles. The contents of
each column are described in the subsections that follow.
Virtual Storage column contents
As shown in Figure 4-15 , this column displays the virtual storage devices in the virtual machines.
The virtual storage devices are grouped by virtual machine. Each major box grouping in the
column represents a virtual machine.
