Programming
96 NXC-ME260 NetLinx Master-Ethernet Card/Module
Program Port Commands (Cont.)
Command Description
SHOW REMOTE Displays a list of the devices this system requires input from and the types
of information needed. If when a NetLinx Master connects to another
NetLinx Master, the newly connecting system has a device that the local
system desires input from; the new system is told what information is
desired from what device.
Example:
>SHOW REMOTE
Device List of Remote Devices requested by this System
Device Port System Needs
------------------------------------------------------
00001 00001 00001 Channels Commands
00002 00001 00001 Channels Commands
33000 00001 00001 Channels Commands
00128 00001 00108 Channels Commands Strings Levels
33000 00001 00108 Channels Commands
SHOW ROUTE Displays information about how this NetLinx Master is connected to other
NetLinx masters.
E xample:
>SHOW ROUTE
Route Data:
System Route Metric PhyAddress
--------------------------------
-> 50 50 0 Axlink
SHOW SYSTEM Provides a list of all devices in all systems currently on-line. The systems
lists are either directly connected to this Master (i.e. 1 hop away), or are
referenced in the DEFINE_DEVICE section of the NetLinx program.
Optionally, you may provide the desired system number as a parameter to
display only that system's information (e.g. SHOW SYSTEM 2001). The
systems listed are in numerical order.
Example:
>SHOW SYSTEM
Local devices for system #50 (This System)
------------------------------------------------------------
Device (ID)Model (ID)Mfg FWID Version
00000 (00256)Master (00001)AMX Corp. 00256 v2.10.75
(PID=0:OID=0) Serial='2010-12090',0,0,0,0,0,0
Physical Address=NeuronID 000239712501
(00256)vxWorks Image (00001) 00257 v2.00.77
(PID=0:OID=1) Serial=N/A
(00256)BootROM (00001) 00258 v2.00.76
(PID=0:OID=2) Serial=N/A
(00256)AXLink I/F uContr(00001) 00270 v1.02
(PID=0:OID=3) Serial=0000000000000000
00096 (00192)VOLUME 3 CONTROL BO(00001)AMX Corp. 00000 v2.10
(PID=0:OID=0) Serial=0000000000000000
Physical Address=Axlink
00128 (00188)COLOR LCD TOUCH PAN(00001)AMX Corp. 32778 v5.01d
(PID=0:OID=0) Serial=0000000000000000
Physical Address=Axlink
05001 (00257)NXI Download (00001)AMX Corp. 00260 v1.00.20
(PID=0:OID=0) Serial=0,0,0,0,0,0,0,0,0,0,0,0,
Physical Address=NeuronID 000189145801
(00257)NXI/NXI-1000 Boot(00001) 00261 v1.00.00
(PID=0:OID=1) Serial=0,0,0,0,0,0,0,0,0,0,0,0,
10002 (00003)PHAST PLK-IMS (00001)Phast Corp. 0003 v3.12
(PID=0:OID=0) Serial=0000000000000000
Physical Address=NeuronID 0100417BD800
