Chapter 4. Testing Example
4-2 TSU User Manual 61200060L1-1
3. Use the scroll keys to place the cursor on 1)NETWORK
TESTS.
4. Press ENTER to select.
5. Press ENTER again to enter the NETWORK TEST MENU .
The beginning display of the submenu items display. The
selections available for each menu item are selected with the
up and down scrolls.
6. Use the scroll keys to place the cursor on 2)REMOTE
LOOPBK
7. Press ENTER to select
1 ) N E T W O R K T E S T S
2 ) R U N S E L F T E S T
2 ) R E M O T E L O O P B K :
N O L O O P B A C K
4 ) C L R 5 1 1 E R R O R S
5 1 1 E R R O R S = 0
V . 5 4 P L B O N
A T T P L B O N
A T T L L B O N
A N S I L L B O N
A N S I P L B O N
N O L O O P B A C K
1 ) L O C A L L O O P B K :
N O L O O P B A C K
L I N E O N
P A Y L O A D O N
N O L O O P B A C K
3 ) T E S T P A T T E R N :
N O N E
N O P A T T E R N
3 . 2 4 A L L D S 0 s
A L L O N E S
5 1 1 A C T I V E D S 0 s
1 : 8 A L L D S 0 s
