Control in/chain in -3, Table 2-2, Control in/chain in pin connection -3 – ADTRAN T1-FT1 User Manual
Page 33
Chapter 2. Installation
61200060L1-1
TSU User Manual
2-3
Control In/Chain In
Used as an EIA 232 port for connection to a computer or
modem (Chain In); or another TSU (Chain Out).
See Table 2-2.
Connector Type - RJ48
pn - AMP# 555164-2
Table 2-2. Control In/Chain In Pin Connection
CONTROL PIN CONNECTION
PIN
NAME
DESCRIPTION
1
GND
Ground-Connected to Unit Chassis
2
UNUSED
3
RXDATA
Data Received by the TSU
4
UNUSED
5
TXDATA
Data Transmitted by the TSU
6
UNUSED
7
RI
Ring Indicate from Modem
8
UNUSED
