Chapter 2. Installation
2-2
TSU User Manual
61200060L1-1
WIRING
Network
On the rear panel the TSU has an eight-position modular jack
labeled
NETWORK
. This connector is used for connecting to
the network. See Table 2-1 for the pinout for the Network
connector.
Connector Type - (USOC) RJ48C
pn - AMP# 555164-2
Power to the TSU must be from a 115 VAC, 60Hz that is grounded.
Table 2-1. Network Pin Connection
Network Pin Connection
PIN
NAME
DESCRIPTION
1
R1 RXDATA-RING
Receive data from the Network
2
T1 RXDATA-TIP
3
UNUSED
4
R TXDATA-RING
Send data towards the Network
5
T TXDATA-TIP
6, 7, 8
UNUSED
