Chapter 3. Operation
3-6 TSU User Manual 61200060L1-1
Menu Structure
The TSU uses hierarchical menus to access its many features.
The main menu leads to submenus which are grouped by
function. All menu operations are displayed in the LCD
window.
Figure 3-2. The Four Opening Menus
Menu flow is normally depicted from left to right. Arrows on
the lower right of the screen indicate the direction of scrolling
to view additional menu items. At every level of the menu
pressing the
CANCEL button returns the system to the
previous menu level. Pressing the CANCEL button repeatedly
returns the system to the main menu.
1 ) S T A T U S 3 ) U T I L
2 ) C O N F I G 4 ) T E S T
This menu structure diagram is a limited overview. A de-
tailed description of each menu item, presented in menu or-
der is shown in Figure 3-2. A complete menu is shown in
Appendix A.
1 NI PERF REPORTS
1 STATUS 2 CURR ERR/ALM
3 ERR/ALM HIST
1 NETWORK (NI)
2 CONFIG 2 UNIT 1 TIME/DATE
MAIN MENU 3 PORT 2 SOFTWARE REV
3 UTIL 3 REINIT UNIT
4 ADDRESS
1 NETWORK TESTS 5 FACT RESTORE
4 TEST 2 RUN SELFTEST
3 PORT TESTS
