Chapter 2. Installation
61200060L1-1 TSU User Manual 2-5
Nx56k/64k DTE (V.35)
Connector Type = V.35
pn = AMP# 92-4883-3-1
See Table 2-4.
Table 2-4. Primary V.35 Pin Connection
Nx 56k/64/ DTE PIN CONNECTION
PIN CCITT DESCRIPTION
A 101 Protective Ground (PG)
B 102 Signal Ground (SG)
C 105 Request to Send (RTS) from DTE
D 106 Clear to Send (CTS) to DTE
E 107 Data Set Ready (DSR) to DTE
F 109 Received Line Signal Detector (DCD) to DTE
H - Data Terminal Ready (DTR) from DTE
J - Ring Indicator (RI)
L - Local Loopback (LL)
N - Remote Loopback (RL)
R 104 Received Data (RD-A) to DTE
T 104 Received Data (RD-B) to DTE
V 115 RX Clock (RC-A) to DTE
X 115 RX Clock (RC-B) to DTE
P 103 Transmitted Data (TD-A) from DTE
S 103 Transmitted Data (TD-B) from DTE
Y 114 TX Clock (TC-A)
AA 114 TX Clock (TC-B)
U 113 External TX Clock (ETC-A) from DTE
W 113 External TX Clock (ETC-B) from DTE
NN&K - Test Mode (TM) to DTE
