Chapter 10 193
Troubleshooting
No Modulation at the RF Output
There are three power search modes: manual, automatic, and span.
When
Power Search
is set to Manual, pressing
Do Power Search
executes the power search calibration routine
for the current RF frequency and amplitude. In this mode, if there is a change in RF frequency or amplitude,
you will need to press
Do Power Search
again.
When
Power Search
is set to Auto, the calibration routine is executed whenever the frequency or amplitude of
the RF output is changed.
When
Power Search
is set to Span, pressing
Do Power Search
executes the power search calibration routine
over a selected range of frequencies at one time. The power search corrections are then stored and used
whenever the signal generator is tuned within the selected range of frequencies.
No Modulation at the RF Output
Check the MOD ON/OFF annunciator on the display. If it reads MOD OFF , press
Mod On/Off
to toggle the
modulation on.
Although you can set up and enable various modulations, the RF carrier is modulated only when you have
also set
Mod On/Off
to On.
For digital modulation, make sure that
I/Q Off On
is set to On.
