Removing the Launch Board
1. See “Removing the Upper Cover” on page 68.
2. Remove the two screws from the Launch Board.
3. Remove the Launch Board from the Upper Cover.
Step
Size
Quantity
Screw Type
Launch Board
M2*3 (NL)
2
