66 Chapter 3
Removing the LCD Module
1. See “Removing the Battery Pack” on page 44.
2. See “Removing the Lower Covers” on page 47.
3. See “Removing the WLAN Module” on page 50.
4. See “Removing the Keyboard” on page 61.
5. See “Removing the Antenna” on page 63.
6. Remove the two securing screws from the bottom of the chassis.
7. Turn the computer over. Disconnect the three LCD interface cables from the chassis.
Step Size Quantity Screw Type
LCD Module M2.5*8(NL) 2
