External Module Disassembly Process
External Modules Disassembly Flowchart
The flowchart below gives you a graphic representation on the entire disassembly sequence and instructs you
on the components that need to be removed during servicing. For example, if you want to remove the main
board, you must first remove the keyboard, then disassemble the inside assembly frame in that order.
Screw List
Step Screw Quantity Color Part No.
Memory Cover M2.5*8 (NL) 2 Black 86.AR102.001
WLAN Cover M2.5*8 (NL) 1 Black 86.AR102.001
WLAN Module M2*3 (NL) 2 Black 86.AR102.004
HDD Carrier M3*3 (NL) 4 Silver 86.AR102.009
ODD Module M2.5*5(NL) 1 Black 86.AR102.002
ODD Bracket M2*3 (NL) 3 Black 86.AR102.004
Remove
Lower Covers
Remove
Express Dummy
Card
Disconnect power
and signal cables
from system
Remove Battery
Turn off system
and peripherals
power
Remove
SD Dummy Card
Remove
DIMM Modules
Remove
ODD Module
Remove
WLAN Board
Remove
HDD Module
Remove
HDD Bracket
Remove
HDD
Remove
ODD Bracket
Remove
ODD
Remove
WLAN Antenna
