26 Chapter 1
LCD Camera
LCD Inverter
AC Adapter
System Power Management
Support Color greater than 262144
Viewing Angle (degree)
Horizontal: Right/Left
Vertical: Upper/Lower
Minimum: 40/40, Typical: 45/45
Minimum: 10/30, Typical: 20/35
Temperature Range (°C)
Operating
Storage (shipping)
0 to +50
-20 to +60
Item Specification
Vendor Bison
BN30V4O7-010 Sirtek
CN0314-SN30-OV03-1 Suyin
CN1014-S36B-OV01
Focusing range Fixed 40 cm to infinity 40 cm to infinity
Dimension
(L x W x H mm) W9 * L65 * H5.3 mm 65 * 9.0 * 5.30 mm
+/-0.20 mm 65 * 9.0 * 5.26 mm
Sensor Up to SXGA (1280x1024)
size CMOS sensor OV7725 CMOS Sensor
350K Pixel 1.0 Megabit CMOS
Sensor
Pixel Resolution 640(H) * 480(V) VGA 640 * 480 1280X800
Pixel Size 6.0µm * 6.0µm 6.0 µm * 6.0 µm 3.0µm * 3.0µm
Item Specification
Vendor & model name YEC YNV-C01H
Brightness conditions N/A
Input voltage (V) 9~20(V)
Input current (mA) Typical 0.33(mA)
Output voltage (V, rms) Typical 650 Vrms
Output current (mA, rms) MAX. 6.8mA
Output voltage frequency (k Hz) 45~65 (KHz)
Item Specification
Input rating 100~240Vac/ 50-60Hz
Maximum input AC current 1.5A
Inrush current No damage
Efficiency Meet EPA level-4 requirement
Item Specification
Features • Mech. Off (G3)
• Soft Off (G2/S5)
• Working (G0/S0)
• Suspend to RAM (S3)
• Save to Disk (S4)
Item Specification
