13.0 SPARE PARTS & ACCESSORIES
Part #
Item
269701 269 terminal block
269425-02 security key
869902 accessory bag
869904-xx electro-pnuematic harness; 2 wire
869905-xx electro-pnuematic harness; 4 wire
869909 terminal, fork, 18AWG; #6
869910 mini-alligator clip
869912-xx shrouded banana plug
869913 Pocket PC, USB cradle
869914 Pocket PC; power adapter, universal
869920 harness cable end assy, 2 wire
869921 harness cable end assy, 4 wire
869901 Pocket PC screen protector
869922 pre-programmed Pocket PC
869923 acessory kit
869924 stylus, 3 pack
406731 Littlefuse # 0218.063HXP = 5 x 20 mm; 0.63 ma;
time lag; 250vAC rating
869714 Littlefuse # H217004 = 5 x 20 mm; 4 A ; fast
acting; 250vAC rating
869969-06 EPIC Cable - 6 feet
869969-12 EPIC Cable - 12 feet
9
5.0 CALIBRATOR SETUP
5.1 BATTERY CHARGING
The Calibrator is assembled, calibrated and tested at the factory. The
battery, as received, will be in a partially charged state. Before operation
please be sure to fully charge the battery to get maximum portable use of
the device.
TO CHARGE THE BATTERY:
• If calibrator is not in use for more than one month, Pocket PC
should be plugged into HP supplied power cable or be left
connected to AC power supply.
• Connect the AC power adaptor to AC supply connector on back of unit.
(shown in Diagram 3B)
• Battery charging will take approximately 6-8 hours.
5.2 POCKET PC CHARGING
TO CHARGE THE POCKET PC:
• Pocket PC will only charge from calibrator when the unit is on or A/C
adapter is plugged in.
• Pocket PC must remain charged.
• Drained to the point that the Pocket PC is at zero, the Pocket PC will
need to be plugged into a 5V adapter and charged to a minimum of 5%
before starting calibrator software . Battery charge can be checked
by going to: Start Menu > Settings > System > Power.
