27
Diagram 17
Default System
Setting
Eng. Units Setting
Software Version
Firmware Version
Serial Number
Filter Length
Excitation
Battery Level
Leak Test System
Communication
On/Off Selector
Next Calibration
Due Date
Current Date
Diagram 20
Press to set units to
presently selected
Units Selector
Radio Buttons
Press to exit w/out
changing units
ENGINEERING UNITS SCREEN
This page is used to convert the displayed engineering units on the
Pocket PC. All values are stored as a default in WC. Displayed values
are then converted using conversion values below.
Conversions:
Unit Abbr. Unit Name inWC Value Unit Value
inWC@20C Inches Water Column @ 20 C 1.0 1.0
inWC@4C Inches Water Column @ 4 C 1.0 0.9982388185
kPa Kilo Pascal 1.0 0.2486491
Pa Pascal 1.0 248.6491
mbar Millibar 1.0 2.486491
cmWC Centimeters Water Column 1.0 2.54
mmWC Millimeters Water Column 1.0 25.4
