Setra System Model LD330 - Manual

Setra Local Display
Model LD330
Installation and Operating Instructions.
Setra’s Model LD330 is a small local display designed for convenient
in-line installation. It can be used with voltage output and current output tranducers
4-pin bayonet connectors (which meet dimensional requirements of MIL-C-26482
and the MIL STD 3116) Amp jack, 15 Pin and
9 Pin D-Sub connectors.
1.0 INSTALLATION
The LD330 can be supplied with a variety of integral electrical connectors to connect to the
mating connectors on the transducer. Consult part number chart below to determine the
proper configuration. For setting optimum viewing angle, the LD330 display housing can
rotate, at least 270 degrees, with respect to the connector. DO NOT ATTEMPT TO FORCE
ROTATIONAL ADJUSTMENT BEYOND STOP POSITION.
The LD330 is available in a variety of configurations.
1
9 PIN 15 PIN 5 PIN
CABLE BAYONET D-SUB D-SUB MINI-DIN MOLEX
CONNECTION WIRE PIN PIN PIN PIN
+ EXCITATION RED A 4 7 1 2
+ OUTPUT GREEN B 1 2 2 1
– OUTPUT WHITE C 8 12 4 4
– EXCITATION BLACK D 9 5 5 5
CASE GND DRAIN SHELL SHELL SHELL 3 6
9 PIN 15 PIN 5 PIN
CABLE BAYONET D-SUB D-SUB MINI-DIN MOLEX
CONNECTION WIRE PIN PIN PIN PIN
+ EXCITATION RED A 4 7 1 2
– EXCITATION BLACK D & B 9 5 4 5
CASE GND DRAIN SHELL SHELL SHELL 3 6
2.0 ELECTRICAL CONNECTIONS
The LD330 can be supplied with different style connectors to the input transducer and to
the power supply. The power supply can be supplied with cable, also. Confirm the electrical
connection supplied , and refer to the appropriate column below for
proper connections.
2.1 Voltage Units
2.2 Current Units
