Initial Configuration
Use
Remote Organization
STHome
Your Computer
TCP/IP
5 PPPoAĆtoĆPPTP Relaying for Microsoft Windows
24 / 88
3EC 17058 AAAA TCZZA Ed. 02
5.1 Getting Started with PPPoAĆtoĆPPTP Relaying
1. Connect your Speed Touch  Home and PC(s) as described in
Chapter 3.
2. Determine your PC's OS. If:
D Windows 98 (or later) : Continue with step 4.
D Windows 95 : Continue with step 3.
D Windows NT : Go to section 5.7.
3. Download the DialĆUp Networking Upgrade for Windows 95
and install it as described in section 5.5.
4. Configure a Private IP address on your PC, e.g. 10.0.0.1.
5. Configure your PPP/PPTP DialĆUp connection icon(s) as
described in section 5.3.
6. Establish the connection by double clicking the icon of the
appropriate PPP/PPTP connection (See section 5.4.1).
7. You are now connected: start your application, e.g. a Web
browser.
5.2 Requirements
Must support RFC2364 PPP Encapsulation on ATM.
Additionally, it provides you with:
"
The VPI/VCI values for PPP service
"
A User Account for access to its network or the Internet.
Should you want connectivity to multiple remote organizations,
additional sets of these parameters need to be supplied.
Comes with 4 preconfigured PPPoA/PPTP connections. Up to 12
concurrent virtual channels are supported; all can be assigned to
PPP/PPTP. The actual number might be restricted by the ADSL
provider.
Must support the PointĆtoĆPoint Protocol (PPP) and PointĆtoĆPoint
Tunneling Protocol (PPTP).
Prior to establishing PPTP tunnels, IP addresses must be properly
configured in both machines, i.e. the PC and STHome, initiating and
terminating the PPTP tunnel.
Therefore, configure a static IP address, or enable DHCPĆclient in
your PC(s). The STHome DHCP server is by default disabled. In case
you enable the DHCPĆclient in your PC, you also must enable a DHCP
server, e.g. the STHome.
