6.5.6 Current Output
Scroll to “ CURRENT OUTPUT ” from “ INTERFACE ” options using the ▲▼ keys and press ENTER.
Use the ◄► keys on to either disable or enable the Current Output.
The configuration of the Current Output should be set under the output config menu. Refer to section
(6.4.5) for more details.
A prompt will be shown to set this value as a default setting.
Whenever the Current Output is enabled a check mark showing that this feature is enabled will be seen
on the display.
RELAY2 OUTPUT
VOLTAGE OUTPUT
► CURRENT OUTPUT
POWER OUTPUT
SELECT DESIRED
ACTIVITY
USING ◄,► KEYS
[ENABLE]
WOULD YOU LIKE
TO SAVE AS
DEFAULT?
