6.1.3.4 Sensor Capacity
Scroll to “ SENSOR CAPACITY ” from “ NEW CHANNEL ” using the ▲▼ keys and press ENTER.
“ SENSOR CAPACITY ” can also be selected from “ EDIT CHANNEL ” to make modifications on the
existing channels except channel one.
Using the
◄► keys move the cursor to the desired placement and use the ▲▼ keys to select the desired
number or decimal position. The capacity can be selected from 0.00001 to 9999999.
OPERATION
WAS EXECUTED
SUCCESSFULLY
(HIT ENTER/BACK)
SELECT DESIRED
VALUE
USING ARROW KEYS
[2.00000]
SENSOR CONFIG
DIRECTION
UNIT SELECTION
► SENSOR CAPACITY
