Built-in shunt calibration features with indicator

Lockout feature to prevent inadvertent changes

Data logging with up to 21,000 points

Supports USB link port

Built-in load cell excitation voltage

Selectable automatic display shutoff for period of inactivity (up to 15 minutes)

Selectable latched or non-latched alarm configuration

ASCII Stream Output.

Two independently isolated solid state alarm relays, each one able to be disabled or enabled
individually, with normally open or closed operations and protected at 110mA/110V

Selectable voltage output as bipolar (±5 V) or uni-polar (0-5 V) with 2.5V offset

Selectable current output as bidirectional and unidirectional

Selectable 0-20mA, 0-25mA, 4-20mA, 5-25mA current output

Selectable alarm configuration (Latched or non-Latched)

Provides a +5.000 V (±1 mV) excitation voltage to bridge resistances as low as 30 Ohms and as
high as 30k Ohms with a limited current to 160 mA

Default channel calibrated to 0-4 mV/V using precision BLH

Back lit 4x16 character LCD with selectable brightness, contrast, and auto shut off

Selectable digit height size (4.75 mm and 12.55 mm)

Selectable number of digits to be displayed, excluding the decimal point (3, 4, 5, or 6)

Equipped with the diagnostic mode to measure bridge resistance, sensitivity, internal voltage
(Analog and digital), and temperature

User friendly navigation menu directs users to enable/disable or select/unselect various features
with easy to follow instructions

Ability to store 14+1 sensor profiles including calibration values such as Offset, Full scale,
Loading point(s) , Engineering unit , Serial number, Sensor type (Bridge, Voltage , Current) ,
Sensitivity, Alarm limits (High and Low), and all Peak/ Valley (First, Hold, Auto reset)
Threshold values

Active channel number indicator

Black powder coated aluminum enclosure

Lead free/ RoHS compliant parts

ESD, EMI, EFT and short circuit protected input and output, which covers the CE approval
