The shunt key can be pressed any time after the device has been calibrated and a new sensor profile has
been loaded. The simulated value is to be used as a calibration reference. SHUNT will blink on the
display.
When both SHUNT and HOLD are active on the last row, the display will switch between blinking
SHUNT and blinking HOLD.
The Channel Key will allow you to view the
channel information.
CHANNEL 01
SERIAL
1
SENSOR BRIDGE
+2.00000
mV/V
+3.03461
Peak
+3.03460
mV/V
+1.59484 Valley
01 Gross SHUNT
