6.4.2 Alarm Relay 1
Alarm relay 1 is a solid state relay with a voltage / current rating of 110V/100mA. Alarm relay 1 has been
mapped to alarm high.
Scroll to “
ALARM RELAY1 ” from “ OUTPUT CONFIG ” using the ▲▼ keys and press ENTER.
Use the ◄► keys to set the alarm relay 1 either to be normally open or normally close.
A prompt will be shown to set this value as a default setting.
SELECT DESIRED
RELAY CONFIG
USING ◄,► KEYS
[NORMALLY OPEN]
DIGITAL ASCII
► ALARM RELAY1
ALARM RELAY2
VOLTAGE CONFIG
WOULD YOU LIKE
TO SAVE AS
DEFAULT?
