Liquid Crystal Display (LCD)
Part #:
CFAH1604B-TMI-ET
Brand: Crystalfontz America, Inc.
Number of Characters
(Width):
16 Characters
No. of Lines (Lines): 4 Lines
Backlight Type & Color: T-LED, white
Fluid Type, Image (Positive
or Negative), & LCD glass
Color:
M-STN, Negative, blue
Polarizer Film Type, Wide
(WT) Temperature Range, &
Viewing Angle (O’clock):
I-Transmissive, WT, 6:00
Character Set (CGROM): English and European fonts
Controller: T-Sitronix ST7066U
Connector Plugs
4 Pin Connector Plug
20020007-H041B01LF
6 Pin Connector Plug 20020007-H061B01LF
8 Pin Connector Plug 20020007-H081B01LF
Power Output
Part#:
DCP020515DU, LM2671
Nominal Output1: 24 V / 50 mA
Nominal Output2: 5 V / 50 mA
Application: Excitation for amplified sensors
Response Times
Conversion capture rate:
every sample
Peak capture rate: every sample
Valley capture rate: every sample
Conversion display update rate: 5 times per second
Peak display update rate:
5 times per second
Valley display update rate: 5 times per second
Bandwidth
The digital output bandwidth has been specified as SPS/4.
The analog output bandwidth has been specified as SPS/4 for sampling rates less than 1200 SPS and has
been specified as SPS/5 for sampling rates more than 1200 SPS if:
a. ASCII stream output is deactivated,
b. IPM650 is not connected to computer,
c. All relays are disabled
d. Display is in menu mode (Peak, Valley, Tracking and data display are main display mode).
