6.2.4 Sampling Rate
Scroll to “ SAMPLING RATE ” from “ SYSTEM SETTING ” using the ▲▼ keys and press ENTER. Using
the ◄► keys, 16 different sampling rates can be selected in two different levels as listed below:
LOW SPEED:
5 , 10 , 25 , 30 , 50 , 60 , 100 , 200 , 400
HIGH SPEED: 600 , 800 , 960 , 1200 , 1600 , 2400 , 4800
Note: During the data logging, Voltage output, Current output, and ASCII output are disabled to get the
maximum data.
See section 6.3 for more information about data logging.
Whenever the sampling rate is changed the system will automatically load the active channel and
perform an auto calibration followed by loading the active channel information.
For bandwidth clarification, see APPENDIX C (DEVICE SPECIFICATIONS).
SELECT DESIRED
SAMPLING RATE
USING ◄,► KEYS
[5 SPS]
CHANNEL SELECT
MOVING AVERAGE
► SAMPLING RATE
PEAK / VALLEY
AUTO CALIBRATION
IN PROGRESS
PLEASE WAIT 15
………
LOADING PROFILE
IN PROGRESS
PLEASE WAIT 30
