6.1.3.8 Serial number
Scroll to “ SERIAL NUMBER ” from “ NEW CHANNEL ” using the ▲▼ keys and press ENTER. “ SERIAL
NUMBER ” can also be selected from “ EDIT CHANNEL ” to make modifications on the existing channels
except channel one.
Using the ◄► keys, the cursor can be moved among the seven digits and use the ▲▼ keys to select the
desired serial number.
A confirmation message will be displayed confirming operation was successfully executed.
OPERATION
WAS EXECUTED
SUCCESSFULLY
(HIT ENTER/BACK)
SELECT DESIRED
VALUE
USING ARROW KEYS
[0000000]
CALIBRATION
PULSE/ROTATE
► SERIAL NUMBER
LIMIT & THD
