9 Appendix C (Device Specifications)
Main Control Processor Unit (MCPU)
Part #:
MSC1214
Internal ADC Resolution:
24 bits
Sampling Rate:
60 SPS
Application:
Diagnostic mode
DAC Resolution: *
16 bits
DAC Accuracy: *
0.02% of FSR (Factory Calibrated)
DAC Non linearity:*
0.1% of FSR (Factory Calibrated)
Application:*
Voltage output/ Current output
Analog to Digital Converter (ADC)
Part #:
AD7190
Recommended Load:
30 to 30000 Ω
Bridge Excitation:
5.000 V ± 1 mV (limited current to 160 mA)
Input Range:
±2.5V (0-500 mV/V)
Channel 1 for bridge
Input Range:
±12 V
Channel 2 for Voltage/Current input
Sampling rate:
up to 4800 SPS
Non linearity:
± 5 PPM for FSR
Offset Drift vs. temperature:
± 5 PPM/°C
Span Drift vs. temperature:
± 5 PPM/°C
Application:
Signal measurement
Voltage Reference
Part #:
MAX6126AASA25+
Accuracy:
± 0.02%
Nominal Voltage:
2.5 V
Temperature Shift:
± 3 PPM/°C
Application:
Reference Voltage / Excitation voltage
Power Requirement
Power Supply Adapter:
12 VDC/ 1 A
Solid State Relays
Part #:
G3VM-2F
Application:
Alarm relay 1, 2
Maximum Output Voltage:
250 V (AC or DC)
Maximum Output Current:
120 mA
Note: Internally limited and protected to 110 V/100 mA
