6.9.1 Internal or External
Scroll to “ DIAGNOSTIC ” using the ▲▼ keys and press ENTER.
Use the ◄► keys to select either INTERNAL or EXTERNAL diagnostic.
The internal diagnostic shows the analog VDD1, analog VDD2, digital VDD, and VBAT values.
The external diagnostic shows the sensor sensitivity, Temp, and bridge resistance.
NOTE:
The external diagnostic page can only show the information of a Strain gage with the sensitivity of less
than 4mV/V. If the sensor is amplified voltage output or current output or has a sensitivity more than 4
mV/V, when trying to display External Diagnostic, an error message will appear stating that this function
is not available.
TEMP(°C): +28°C
TEMP(°F): +82°F
BRIDGE : 350 Ω
+2.34567 mV/V
SELECT DESIRED
DIAGNOSTIC
USING ◄,► KEYS
[EXTERNAL]
AVDD1 : 4.999V
AVDD2 : 5.200V
DVDD : 5.001V
VBAT : 8.500V
SELECT DESIRED
DIAGNOSTIC
USING ◄,► KEYS
[INTERNAL]
