6.5.4 Relay 2 Output
Scroll to “ RELAY OUTPUT2 ” from “ INTERFACE ” using the ▲▼ keys and press ENTER.
Use the ◄► keys to either disable or enable the Relay 2.
The configuration of the Relay 2 Output should be set under the output config menu. Refer to section
(6.4.3) for more details.
Relay 2 is mapped to alarm low and will be affected by the alarm settings under the system settings
menu. Refer to section (6.2.8) for more details.
A prompt will be shown to set this value as a default setting.
Whenever the Relay 2 Output is enabled a check mark showing that this feature is enabled will be seen
on the display.
WOULD YOU LIKE
TO SAVE AS
DEFAULT?
SELECT DESIRED
ACTIVITY
USING ◄,► KEYS
[ENABLE]
ASCII OUTPUT
RELAY1 OUTPUT
► RELAY2 OUTPUT
VOLTAGE OUTPUT
