Preparing the IR Camera
Checking the Information on the LCD Monitor
The LCD monitor has a field of vision of 100% of the actual shooting
image.
The following displays in information view.
About the operation indicator
The operation indicator shows the current operation status of
the camera.
Upper limit of
color scale
Operation
indicator
Battery Charge
Time
Color
scale
Reading
Lower limit of
color scale
Activate
/ Freeze
Current
Emissivity
Max. temperature
Min. temperature
