Controls
Display Keypad
Display Keypad Connections
The display keypad is equipped with an LCD display (8 rows x 22 columns) with 6 buttons, connected to the controller by
an RJ11 cable.
Local network
connection, plug
cable into J10 on
PC0 Controller
pGD1 Display
Display Keypad
RJ11
Cable
