Condensing Units
BluCube
™
Condensing Units
47
Installation and Maintenance Manual 7222094: 11/2013
Mechanical Data - Heat Pump Modulating Capacities
CUR092V16-VHP-0
CUR092V20-VHP-0
CUR092V25-VHP-0
Capacity
Nominal Cooling Capacity
(1)
kW
16.4
21.0
25.3
Nominal Heating Capacity
(2)
kW
15.0
19.4
23.2
Capacity Steps
16-100%
16-100%
16-100%
Dimensions
– W x D x H
(3)
mm
922 x 764 x 1736
922 x 764 x 1736
922 x 764 x 1736
Masses
– Machine / Operating
(4)
kg
236
236
262
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint
– Light Grey (RAL 7035)
Material/Colour
Heat Pump Evaporator / Condenser
Rifled Copper Tube/Louvered Hydrophilic Coated Aluminium Fins
Fan Motor
Axial
Motor Type
AC 1ph
AC 1ph
AC 1ph
Quantity x Motor Size
kW
1 x 0.6
1 x 0.6
1 x 0.6
Diameter
mm
630
630
630
Maximum Fan Speed
RPM
860
860
860
Maximum Airflow
m³/s
2.0
2.0
2.0
Compressor
Compressor Type
Modulating Capacity Scroll
Quantity
1
1
1
Oil Charge Volume
1.9
1.9
3.2
Oil Type
Polyolester
Refrigeration
Single Circuit - 2 pipe configuration
Refrigerant control and type
REEV package
Refrigerant type
R410A
Holding Charge
Inert Gas
Coil Volume
l
9.9
9.9
9.9
Refrigerant Charge
(5)
kg
8.4
8.5
8.9
Connections
Liquid (sweat)
in
3/8
3/8
1/2
Suction / Discharge (sweat)
in
1/2
5/8
7/8
Optional Extras
EC Fan
Quantity x Motor Size
kW
1 x 0.72
1 x 0.72
1 x 0.72
Diameter
mm
630
630
630
Maximum Fan Speed
RPM
1000
1000
1000
Maximum Airflow
m³/s
2.3
2.3
2.3
Dimensions
– W x D x H
(2)
mm
922 x 764 x 1750
922 x 764 x 1750
922 x 764 x 1750
Masses
– Machine / Operating
(3)
kg
228
228
254
Short Case Axial Fan
Designed to 75Pa ESP
Quantity x Motor Size
kW
1 x 1.4
1 x 1.4
1 x 1.4
Diameter
mm
560
560
560
Maximum Fan Speed
RPM
1330
1330
1330
Maximum Airflow
m³/s
2.8
2.8
2.8
Dimensions
– W x D x H
(2)
mm
922 x 764 x 1753
922 x 764 x 1753
922 x 764 x 1753
Masses
– Machine / Operating
(3)
kg
242
242
268
REEV Selection
E²V - 24
E²V - 35
E²V
– 35
(1) Evaporating temperature 7°C, Ambient 35°C with an AC fan matched with a REEV package
(2) Condensing temperature 50°C, Ambient 5°C with an AC fan matched with a REEV package
(3) Overall dimensions for clearance
(4) Unit mass excludes a refrigerant charge
(5) For guidance only
