Technical Data Heat Pump
Operational Limits
Typical Heating Application Envelope
28, -13
26, -15
28, 25 12, 25
12, -15
-20
-15
-10
-5
0
5
10
15
20
25
30
0 5 10 15 20 25 30
Return Air Temperature (°C)
A
m
bi
e
nt
Te
m
pe
ra
ture
(
°C
)
CAUTION A minimum air on temperature limit of 12°C must be adhered to ensure correct unit
operation.
Any fresh air introduced to the unit must have pre-heaters to maintain this
minimum temperature.
Operating Limits - Heat Pump Heating Cycle
-15, 25
-15, 38
25, 60
25, 25
13, 60
-20, 25
-20, 38
0
10
20
30
40
50
60
70
-25 -20 -15 -10 -5 0 5 10 15 20 25 30
Ambient temperature (°C)
C
on
de
ns
ing
t
e
m
pe
ra
ture
(
°C
)
Fixed Capacity Modulated Capacity
Data Based on a 12°C

T across coil.
