BluCube
™
Condensing Unit
36
Condensing Units
Installation and Maintenance Manual : 7222094 11/2013
Electrical Data
– Cooling Only Continued
CUR092V16-VCO-0
CUR092V20-VCO-0
CUR092V25-VCO-0
Unit Data
(1)
Nominal Run Amps
A
12.2
15.7
18.2
Maximum Start Amps
A
67.7
104.7
114.7
Recommended Mains Fuse Size
A
20
25
25
Max Mains Incoming Cable Size
mm²
35
35
35
Mains Supply
V
400V / 3PH + N / 50Hz
Control circuit
VAC
24
24
24
Condenser Fan - Motor
Motor Type
AC
AC
AC
1~
1~
1~
Quantity x Motor Size
kW
1 x 0.6
1 x 0.6
1 x 0.6
Full Load Amps
A
2.7
2.7
2.7
Locked Rotor Amps
A
9.2
9.2
9.2
Compressor
Motor Size
kW
5
7
8
Nominal Run Amps
A
8.6
12.1
14.5
Locked Rotor Amps
A
64
101
111
Type of Start
Direct On Line
OPTIONAL EXTRAS
Electronic Soft-start
Nominal Run Amps
A
12.2
15.7
18.2
Maximum Start Amps
A
42.1
64.3
70.3
Recommended Mains Fuse Size
A
20
25
32
Power Factor Correction
N/A
N/A
N/A
Nominal Run Amps
A
N/A
N/A
N/A
Maximum Start Amps
A
N/A
N/A
N/A
Recommended Mains Fuse Size
A
N/A
N/A
N/A
Compressor Nominal Run Amps
A
N/A
N/A
N/A
First upgrade EC Motor
1~
1~
1~
Quantity x Motor Size
kW
1 x 0.72
1 x 0.72
1 x 0.72
Full Load Amps
A
3.3
3.3
3.3
Locked Rotor Amps
A
N/A
N/A
N/A
Second upgrade SCAF
1~
1~
1~
Quantity x Motor Size
kW
1 x 1.4
1 x 1.4
1 x 1.4
Full Load Amps
A
6
6
6
Locked Rotor Amps
A
18
18
18
(1) Based upon ARI conditions, Evaporating at 7°C, Condensing at 54.4°C.
