50 BM 70 M
PROFIBUS-PA:
(special signal output required)
The PROFIBUS-PA is defined and standardised in DIN 19245, Parts 1 and 2. A large number of
devices with PROFIBUS-PA capability are available on the market. The BM 70 M is easy to
connect to such bus systems; it has a purely slave function and allows access to all dynamic
values and to setting parameters. The hardware interface we use is the intrinsically safe bus
interface.
For further information, please ask for the "BM70A/P PROFIBUS-PA" description.
F.FOUND.:
(special signal output required)
Bus interface in conformity with the "Foundation Fieldbus" (FF). For further information, please
ask for the "BM70A/P Foundation Fieldbus " description.
- in preparation -
8.6.10 Display
Language of display texts
A choice of languages for the display texts is offered in Fct. 3.4.1.
GB/USA English
E Spanish (Español)
D German P Portuguese
F French S Swedish
I Italian
Coding desired for entry into setting level?
Set NO or YES in Fct. 3.4.2 ENTRY.CODE1.
• If NO set, simply press key WRJHWLQWRWKHVHWWLQJOHYHO
•
If YES set, press key
→
and then a 9-keystroke combination to get into the setting level.
• Factory-set Entry Code 1:
→→→↵↵↵↑↑↑
•
To change Entry Code 1
Select Fct. 3.4.2 ENTRY CODE 1: set to YES.
Select Fct. 3.4.3 CODE 1.
Press key
→ , display shows: CODE 1 _ _ _ _ _ _ _ _ _
Key-in required 9-keystroke combination; each keystroke confirmed by "*". Then press the
same keystroke combination again. "WRONG CODE" (= incorrect entry) appears if 1st and
2nd entries are not equal.
Press keys
↵
and
→
and repeat entries.
Take good note of the selected entry code!
Measuring-point identification (tag name)
• A max. 8-figure tag name can be set under Fct. 3.4.4 LOCATION (e.g. L123 A53)
•
Characters assignable to each of the 8 places:
alpha characters A-Z / a-z; numbers 0-9; special signs: + - ; blanks (= underscore character)
Factory setting: RADAR 000
