BM 70 M 31
8.2 Function of the keys
The three keys have the following functions:
→ (Cursor key): - selects the configuration menu
- branches the menu to the next lower level,
- moves the cursor* to the right to the next column.
↑ (Select key): - branches the menu to the next digit in the same
level,
- changes the content (digit, character) at the cursor*
position.
↵ (Enter key): - selects the error memory,
- branches the menu to the next higher level,
- stores newly entered parameters,
- executes displayed functions.
* The cursor position is signalled by flashing of the character or selected point at the appropriate
place.
To start operator control:
Measuring mode Operator control mode
627 Fct. 1.0
cm
→
OPERATION
Note:
When "YES" is set under Fct. 3.4.2 and ENTRY CODE "CodE1 -------" appears
in the display, the
→ key must be pressed
The 9-keystroke Entry Code1 must then be entered:
Factory setting:
→→→↑↑↑↵↵↵ (each keystroke confirmed in the display by "*".)
To terminate operator control:
Press key ↵ repeatedly until one of the following menus is displayed.
Fct. 1.0 OPERATION, Fct. 2.0 TEST or Fct. 3.0 INSTALL.
Measuring mode ↵ Press key...... Operator control mode
Fct. 3.0
INSTALL
↵
STORE YES
New parameters not to be
stored
Press ↑ key to display
"STORE.NO". Measuring mode
continued with the "old"
parameters after pressing the
↵
key; the "START" message is
shown until a measured value is
determined.
If instead you wish to return to
Configuration, press the
↑ key first
until "RETURN" is displayed, and
then the
↵ key.
Store new parameters
Confirm by pressing the NH\
"START" is displayed, and the
measuring mode is continued with
the new parameters.
