OPERATION
6
51
OPTIWAVE 6300 C
www.krohne.com 03/2014 - 4000547004 - HB OPTIWAVE 6300 R04 en
B. Test
A.4 Quick Link 3
A.4 Quick Link 3 Direct link to an item in the
Advanced Setup menu
Go to a function in the
Advanced Setup menu and
push [>>>>] for 1 second. You
can store up to 5 functions
in this way.
Language
A.5 Quick Link 4
A.5 Quick Link 4 Direct link to an item in the
Advanced Setup menu
Go to a function in the
Advanced Setup menu and
push [>>>>] for 1 second. You
can store up to 5 functions
in this way.
Length Unit
A.6 Quick Link 5
A.6 Quick Link 5 Direct link to an item in the
Advanced Setup menu
Go to a function in the
Advanced Setup menu and
push [>>>>] for 1 second. You
can store up to 5 functions
in this way.
Display
Mode
1 This range depends on other user functions
2 This value depends on other user functions
3 This step is ignored if you use the "Complete" setup mode
4 Optional
Menu
No. Function Function description Selection list Default
B.1 Test
B.1.1 Show Output 1 This displays analogue output 1 value
[mA].
Read only
B.1.2 Set Output 1 This sets analogue output 1 to a test
value [mA] selected from a list. Output
will change to the selected value,
independent of the measured value.
3.6, 4, 6, 8, 10, 12, 14, 16, 18, 20 or
22 mA
4 mA
B.1.3 Show Output 2 This displays analogue output 2 value
[mA].
Read only
B.1.4 Set Output 2 This sets analogue output 2 to a test
value [mA] selected from a list. Output
will change to the selected value,
independent of the measured value.
3.6, 4, 6, 8, 10, 12, 14, 16, 18, 20 or
22 mA
4 mA
B.1.5 Internal Test This initiates the hardware test. The
device displays the results.
Read only
B.2 Information
B.2.1 Outputs Analogue output settings. This includes
assigned functions, 4 … 20 mA scale
settings, error handling and HART
®
parameters.
Read only
B.2.2 15 Min Log A log of output values for the last 15
minutes. A log is taken every 10
seconds and displayed on a graph.
Read only
Menu
No. Step Function Function description Selection list Default
