APPENDIX
10
109
OPTIWAVE 6300 C
www.krohne.com 03/2014 - 4000547004 - HB OPTIWAVE 6300 R04 en
Antenna extension Antenna extension Antenna extension Antenna extension
0 Without
1 Extension 105 mm (4.13¨)
2 Extension 210 mm (8.27¨)
3 Extension 315 mm (12.40¨)
4 Extension 420 mm (16.54¨)
5 Extension 525 mm (20.67¨)
6 Extension 630 mm (24.80¨) 2
7 Extension 735 mm (28.94¨) 2
8 Extension 840 mm (33.07¨) 2
A Extension 105 mm (37.21¨) 2
B Extension 1050 mm (41.34¨) 2
Flange plate protection Flange plate protection Flange plate protection Flange plate protection
P Flange plate protection (PP) DN80, DN100, 3¨, 4¨, 80A, 100A 3
R Flange plate protection (PP) DN150, 6¨, 8¨ 3
S Flange plate protection (PTFE) DN80, DN100, 3¨, 4¨, 80A, 100A 3
T Flange plate protection (PTFE) DN150, 6¨, 8¨ 3
Feedthrough / Temperature / Sealing Feedthrough / Temperature / Sealing Feedthrough / Temperature / Sealing Feedthrough / Temperature / Sealing
Non-Ex devices with a Drop antenna
X Standard / -40...+150°C (-40…+302°F) / FKM/FPM
Y Standard / -50…+150°C (-58…+302°F) / EPDM
Other devices
0 Standard / -40...+150°C (-40…+302°F) / FKM/FPM
1 Standard / -20...+150°C (-4…+302°F) / Kalrez 6375
2 Metaglas® / -30...+150°C (-22…302°F) / FKM/FPM
3 Metaglas® / -20...+150°C (-4…+302°F) / Kalrez 6375
4 Standard / -50...+150°C (-58…302°F) / EPDM
5 Metaglas® / -30...+150°C (-22…+302°F) / EPDM
F Standard / -40...+200°C (-40…+392°F) / FKM/FPM with distance piece included
G Standard / -20...+200°C (-4…+392°F) / Kalrez 6375 with distance piece included
H Metaglas® / -30...+200°C (-22…+392°F) / FKM/FPM with distance piece included
K Metaglas® / -20...+200°C (-4…392°F) / Kalrez 6375 with distance piece included
Process connection EN Process connection EN Process connection EN Process connection EN
0 Without
3 G 1½A ISO 228
7 DN80 PN40 Form B1 EN 1092-1
8 DN100 PN16 Form B1 EN 1092-1
A DN100 PN40 Form B1 EN 1092-1
B DN150 PN16 Form B1 EN 1092-1
C DN150 PN40 Form B1 EN 1092-1
D DN200 PN16 Form B1 EN 1092-1
E DN200 PN40 Form B1 EN 1092-1
VF63 VF63 VF63 VF63 4 Order code (complete this code on the pages that follow) Order code (complete this code on the pages that follow) Order code (complete this code on the pages that follow) Order code (complete this code on the pages that follow)
