10
APPENDIX
110
OPTIWAVE 6300 C
www.krohne.com 03/2014 - 4000547004 - HB OPTIWAVE 6300 R04 en
Process connection ASME Process connection ASME Process connection ASME Process connection ASME
0 Without
3 1½ NPT
A 3¨ 150 lb RF ASME B16.5
B 3¨ 300 lb RF ASME B16.5
C 4¨ 150 lb RF ASME B16.5
D 4¨ 300 lb RF ASME B16.5
E 6¨ 150 lb RF ASME B16.5
F 8¨ 150 lb RF ASME B16.5
Process connection other Process connection other Process connection other Process connection other
0 Without
7 10K 80A RF JIS B2220
8 10K 100A RF JIS B2220
Output Output Output Output
0 1 output: 4…20 mA (HART®)
2 2 outputs: 4...20 mA (HART®) + 4...20 mA
Housing / Cable entry / Cable gland Housing / Cable entry / Cable gland Housing / Cable entry / Cable gland Housing / Cable entry / Cable gland
0 Aluminium / M20 × 1.5 / without
1 Aluminium / ½ NPT / without
2 Aluminium / G ½ / without
3 Aluminium / M20 × 1.5 / plastic (non-Ex: black, Ex ia: blue)
4 Aluminium / M20 × 1.5 / metal (only for Ex d)
A Stainless steel / M25 × 1.5 / without
B Stainless steel / ½ NPT / without
D Stainless steel / M25 × 1.5 / plastic M20 (non-Ex: black, Ex ia: blue)
E Stainless steel / M25 × 1.5 / metal M20 (only for Ex d)
Housing option Housing option Housing option Housing option
0 Without
2 Weather protection
HMI (display and keys) HMI (display and keys) HMI (display and keys) HMI (display and keys)
0 Without
1 English
2 German
3 French
4 Italian
5 Spanish
6 Portuguese
7 Japanese
8 Chinese (simplified)
A Russian
VF63 VF63 VF63 VF63 4 Order code (complete this code on the pages that follow) Order code (complete this code on the pages that follow) Order code (complete this code on the pages that follow) Order code (complete this code on the pages that follow)
