GDS-2000 Series Training Manual
18
G
DS-2000 ADVANCED
Using the demo board designed specially for GDS-2000, you can
verify and observe various GDS-2000 advanced functionalities for
demonstration or your own education.
Required tools
 GDS-2000 x 1
 Demo board x 1
 USB type A – type B x1 cable for demo board power supply
 Standard oscilloscope probe x 2
 BNC-BNC cable x 1 (only for 1GSa/s & Single shot)
Demonstration type
1GSa/s & Single shot Automatic measurement
FM signal observation Long memory
Peak detection Pulse width trigger
Roll / Scan mode X-Y mode
* DAC simulation demo is available when used with GLA (page38).
How to run demonstration
1. Setup the demo board according to the procedure on page20.
2. Pick up the demonstration topic and run it. Resetting GDS-2000
after each demo, according to page20, is recommended.
